well beveled ends with oil finish seamless carbon steel pipe
ASTM A335 Chrome Moly Pipe
ASTM A335 Seamless Ferritic Alloy-Steel Pipe for High-Temperature service. Pipe ordered to this specification shall be suitable for bending, flanging, and similar forming operations, and for fusion welding. Sometimes referred to as “P Grade”, chrome moly pipe is popular in P-Grades P5, P9, P11, P22, and P91. The most common use of grades P11, P22, and P91 is in the power industry and petro-chemical plants, Grades P5 and P9 are commonly used in refineries.
A335 is often called chrome moly pipe because of the chemical makeup of Molybdenum (Mo) and Chromium (Cr). Molybdenum increases the strength of steel as well as the elastic limit, resistance to wear, impact qualities, and hardenability. Moly increases the resistance to softening, restrains grain growth and makes chromium steel less susceptible to embrittlement. Moly is the most effective single additive that increases high temperature creep strength. It also enhances the corrosion resistance of steel, and inhibits pitting. Chromium (or chrome) is the essential constituent of stainless steel. Any steel with 12% or more Chrome is considered stainless. Chrome is virtually irreplaceable in resisting oxidation at elevated temperatures. Chrome raises the tensile, yield, and hardness at room temperatures. The composition chrome moly alloy steel pipe make it ideal for use in power plants, refineries, petro chemical plants, and oil field services where fluids and gases are transported at extremely high temperatures and pressures.
Grades: P-5, P-9, P-11, P-22, and P-91
Sizes
NPS 1/4'' to NPS 48''
Wall Thickness - Schedules 10 through 160, STD, XS, XXS.
Unscheduled heavy wall pipe thicknesses available up to 4 inches.
ASTM A355 P22 Seamless Alloy Steel Pipe
| Mechanical properties |
| Material |
Tensile
N/mm2
|
Strength
Min. N/mm2
|
Yield
% min.
|
| A335 P2 |
min. 380 |
205 |
30 |
| A335 P5 |
min. 415 |
205 |
30 |
| A335 P9 |
min.415 |
205 |
22 |
| A335 P11 |
min. 415 |
205 |
30 |
| A335 P12 |
min. 415 |
205 |
30 |
| A335 P22 |
min. 510 |
400 |
20 |
| A213 P91 |
min. 585 |
415 |
20
|
Applications :
- Architectural/Civil Engineering: Cladding, handrails, door and window fittings, street furniture, structural sections, enforcement bar, lighting columns, lintels, masonry supports.
- Transport: Exhaust systems, car trim/grilles, road tankers, ship containers, ships chemical tankers, refuse vehicles.
- Chemical/Pharmaceutical: Pressure vessels, process piping.
- Oil and gas: Platform accommodation, cable trays, sub-sea pipelines.
- Medical: Surgical instruments, surgical implants, food processing.
- Food and Drink: Catering equipment, brewing, distilling, food processing.
- Water: Water and sewage treatment, water tubing, hot water tanks.
- General: Springs, fasteners(bolts, nuts and washers) wire.
